Application：

Stator I.D.：30~100 mm

Stator O.D：Max. 160 mm

Stack Height：Max. 120 rpm

Number Of Slots：8~36 Slots

Specifications：

Operation Method：Pneumatic & Ac Motor

Motor：3 Phase  0.75 kw

Dimension：1400(L)×700(W)×1700(H) mm

Weight：700 kgs

Function：

Microprocessor in this machine ensures it to be suitable for different kind of lacing function. The tension device to adjust the lacing tension is also equipped. Laced coil in the shape of tortoise shell increases the lacing efficiency.

Features：

1. Wide range application is suitable from small stator of fan to big stator of air-conditioner.

2. High lacing speed is up to 220 stitches / min.

3. Neat and uniform bind coil stabilizes quality output and increases product value.
