MODEL

STANDARD

SH-20

CUSTOMISED

SH-20A

Rotor Diameter

Ø42mm～Ø44mm

Ø25mm～30mm

Larger Size Available

Shaft Diameter

Ø8mm

Ø4mm～Ø6mm

Larger Size Available

Movement

Manual Feeding Automatic Trimming

Trimming Capacity

0.01mm～0.35mm

Concentricity

0.01mm

Knife

Soldered Knife

Oil Pressure Motor

2HP / 30L

Transmission Motor

Induction Motor

Voltage

220V/380V，50HZ/60HZ

Dimension Of Machine

1380(L)×1150(W)×1280(H)

Machine Net Weight

750KG

Dimension Of Wooden Case

1560(L)×1230(W)×1530(H)

Weight Of Wooden Case

250KG
